5500 SLT
All Carriers
Equipment Overview
| Price | Contact for Price |
| Make | RAM |
| Model | 5500 SLT |
| Year | 2024 |
| Stock # | 1001020161 |
Need Assistance?
800-724-8766 | 503-982-5095Specifications
- A/C Condition: New
- Air Conditioning: Yes
- Axle: Single
- Cab: Standard Cab
- Collisionmitigationsystem: No
- Color: White
- Cruise Control: Yes
- Differential Lock: No
- Drive: 4x2
- Driver Position: Left Hand Drive
- Engine Brake: No
- Engine Size: 6.7
- EnginesizeUnit: Engine Liter
- Exhaust Brake: Yes
- Front Axle Lbs: 7000
- FrontaxlelbsUnit: Pound
- Fuel Type: Diesel
- Glider Kit: No
- Gross Vehicle Weight: 19500
- Gross Vehicle Weight Rating: Class 5
- GrossvehicleweightUnit: Pound
- Headache Rack: No
- Heated Mirror: Yes
- Horsepower: 325
- HorsepowerUnit: Horsepower
- Hours Meter Inaccurate: 0
- Mileage: 211
- MileageUnit: Mile
- Navigation: No
- Num Speeds: 6 Spd
- Overhaul: No
- Power Locks: Yes
- Power Steering: Yes
- Power Windows: Both
- Ratio: 4.44
- Rear Axle Lbs: 13500
- RearaxlelbsUnit: Pound
- Rebuilttitle: No
- Super Singles: No
- Suspension: Spring
- Tilt Telescope: Yes
- Tires: 225/70R 19.5
- Transmanufacturer: AISIN
- Transmission: Automatic
- Turbo: Yes
- Wet Kit: No
- Wheel Base: 201
- WheelbaseUnit: Inch
- Wheels: Aluminum
General Description & Dealer Notes
NOT CALIFORNIA COMPLAINT:RAM 5500 SLT Reg Cab w/ Cummins 6.7L I-6 OHV Direct Diesel Injection, 24 Valve Intercooled Turbo, 325HP @ 3,000 rpm, 750 lb-ft @ 1,600 rpm, 136 amp Alternator, 6 Speed Automatic Aisin AS68RC, Exhaust brake. Engine Block Heater, 120" CA, 4 Wheel Disc Brakes w/ Front and rear Vented Discs, Non-Independent Front Suspension, Rear Leaf Suspension, 4 Wheel Anti-Lock Braking System, Daytime Running Lights, Dual Air Bags, A/C, Touch Screen AM/FM/CD Radio, Cruise Control, Power Windows, Power Door Locks, 40-20-40 Split Bench Seat, Vinyl Black Material, Upfitter Switches (5). 19,500 GVWR, Chrome Cab Steps, 22 Gal Fuel Tank, 225/70R19.5 Tires w/ 19.5 Steel Wheels
Chevron 19.6 FT Steel carrier with Independent Wheelift. Full-Length Slide Pads. 8,000lb Winch. Hydraulic pump. Painted Black. Backup lights, backup Alarm. Tow light socket. Bed anti-tilt lockout/ right and left Chain Trays. Safety Chains (2-front, 2 rear) Dual lighted controls. FMVS 108 Lighting group. Wheelift safety pin. Full Height cab protector.Stainless steel tail light plates. Cable Roller guide. Cable tensioner. Positive lock-down. Prewired Junction box. Straps and Ratchets for Wheelift., Ratchets, 11 Chain lock package body- Body Serial # ST10C2E243322
Conventional Wheel-Lift (10-16)
Floor Level Roll Formed with Punched Stake Pockets (Steel)
Standard Approach Plate (Steel)
0- Lights on Pylon
10,000 Lb. Bed Rating
102” Wide (10 & 16 Conventional, Steel)
11 Chain Lock Package - Deck Centered (steel)
12 Volt System
19.5’ (10)
3/16” Deck Plate (Steel)
5-Light Configuration (10/12 Series)
6-Spool Capable
8K Ramsey Worm Gear
Center Mounted Oil Tank
Chain Baskets
LoadRite Gen II (10-16 Chevron)
Marker Lights - 2.5" Round
Outboard Saddle & Cylinders (10)
Passenger Side Winch Clutch Release - Manual
Steel Tube Drop-in L-Arms (4000 Lb., 10-20, 408G2)
Accessories
9-Wire Loop Cable Option (10-40)
Muncie Hot Shift PTO (Allison 1000/2000 or Aisin)
Installation
10 - 16 Car Carrier
Auxillary Fuel Tank
Fire Extinguisher
Front Mudflaps or Quarter Fenders (CC)
Hot Shift PTO - LD, CC, HD
In-Dash Switch Panel
Jump Start Kit
Light Bar (LD/CC)
Misc. Labor
Switch Panel Harness (Required for all LD Installs)
Toolbox (each, CC)
Work Lights (Pair)
Paint
Bed - Factory Black (10-40, Steel)
Paint Cab Protector Optional Color (10-40)
DAA
ACC: ARB Air Compressor High Output On-Board- plus labor
ACC: Air Hose, 50': (F)7092RMA-600; (W)69711; (G)RR30806
ACC: Air Inflate Kit: (F)68272; (W)68271; (G)61387
ACC: Boltcutters, 24"
ACC: Broom & Handle (F)OSB77003+81251; (W)00526CRNM; (G)AME63-15/16X60 + WEI40-25238
ACC: Fire Extinguisher, 5 lb.: (F)466425; (W)B500T; (G)USA10-22
ACC: First Aid Kit: (F)ACE6060; (W)50503L; (G)20229
ACC: Flashlight with DC Charger, Streamlight LED PolyStinger
ACC: Fuel Can, Diesel, 5-Gallon, Yellow
ACC: Fuel Can, Gas, 5-Gallon, Red
ACC: Jack, 2.5-Ton, Aluminum/Steel, Torin
ACC: Lockout Kit, One-Hand Jack Kit
ACC: Lug Wrenchs, 14" Metric/20" Standard
ACC: Pry Bar, 60"/51" (F)AMES1160100; (W)50020; (G)PPB-51
ACC: Shovel (F)AMES1572700; (W)Shovel; (G)Ame73-1564500
ACC: Splitting Maul (F)AMES1113115200; (W)Maul Axe; (G)TJ-8H
ACC: Trash Can, 4-Gallon, Steel
ACC: Triangle Kit
B/M: 2019 RAM Front JSK BRAKT Two Piece assembly
B/M: Circuit Breaker Bracket
B/M: Fuel Filler Neck Bracket for Dodge 5500/Ford F550 Carrier Application
B/M: Toolbox Brackets, LH/RH, with Air Fittings and E-Brake Cable Hole
BOD: Mudflaps, 24" x 30", Pair Dodge F-550 Carrier application
BOD: Pylon, Carrier, Bed-Mount, 2.5" Marker Lights, SS Light Panels, Wire Harnesses
BOD: Quarter-Fender Kit
FT: Dodge 5500 120" CA Transfer Flow Tank, 50 Gallon, with External Hydraulic Tank
HYD: Ball Valve (Shut off for Hydraulic Tank) 1-1/4" or 1"
LB: Whelen Justice™, 12-Head, Amber, 62" Length
LIT: Breaker, 80-Amp, add 1 for each Jumpstart connection
LIT: Jumpstart,Front- Brooking Flush-Mount Kit, with 25' Cables
LIT: Junction Box, 10-Pole
LIT: PTO Light, LED
LIT: Tow Lights, LED, 30' Cord, Round-Magnet
LIT: Worklights, 4" Round, LED HD, Pair, Mounted at Winch, 1200 Lumens
LIT: Worklights, Rectangular, LED HD, Pair, for Lower Worklight (Required on LCG)
SH: Air Coupler, Front (F) 27808; (W) Auto Coupler; (G) 68237
SH: Air Coupler, Passenger-Side Control Station SH: Air Coupler, Front (F) 27808; (W) Auto Coupler; (G) 68237
SH: Shop Supplies
SL: Marker lights ICC Light Bar, Red, Clear-Lens, LED
SL: Optional -Marker Lights, Clear-Lense, for Body.
SL: Park/Turn, Amber, 6", Midship, Oval, LED
SL: Strip Light, 45", White, LED, Mounted on Cab Protector
SL: Strip Lights, 36", White, LED, in Carrier Toolboxes, Pair
SL: Strobes Amber, Corner LED, Pair, for Tailboard Sides, Wire Harness- Fed sig. 5 year warranty
SL: Strobes, Amber Grille Lights, ST-6 Super-Thin, Pair, Chrome Bezels, Backing Plates, Wire Harness
SL: Strobes, Amber, M53, Clear-Lens, LED, Pair, Mounted on top of Midship Turn Signal Boxes, Wire Harness
SL:Park/Turn Midship Turn Signal Boxes, Aluminum, Pair
TB: PolyFloor, Installation
TB: Tool box matting Roll Blk. * Partial Roll useage*
TB: Toolbox Alum. 60" x 18" w/Top Tray Driver side (Econo Version)
TB: Toolbox Alum. 60" x 18" w/Top Tray pass side (Econo Version)
TB: Tray, 18" Z-Bracket, FSW, Aluminum, SS Logo Plates
TOW: 8-Point Tiedown, Chain/Chain
TOW: Bridle, Polyester, Cluster Hook Assemblies
TOW: Chains, 10', 15" J-Hooks, Grade 70, Pair
TOW: Flare Case (Case Only)
TOW: Flares, 6 (F)0730(x6); (W)7703605(x6); (G)100783(x6)
TOW: Lumber, 4" x 4"s, 48" & 60"
TOW: Snatch block 2 ton w- 30" Chain - 3" Sheave Size For -5/16" - 3/8"
TOW: Strap, Steering Wheel
TOW: Tiedown, Cluster, with Chain Ratchet
TOW: Trailer Ball Kit, Convert-A Ball
Notes
Check for back up Camera see if we can hook it up
Use old stock light bar Amber
Use old Stock Grille Strobes
Black pylon
